Name: RELE ESTADO SOLIDO 10A ENT. 4-32VDC SAL. 90-264VAC H
SKU: 5531
Price: 1.00 PEN
Availability: InStock

RELE ESTADO SOLIDO 10A ENT. 4-32VDC SAL. 90-264VAC H

Cod.: HSR-2D102Z

HSR-SLD series- 22.4 ㎜ Ultra slim size
– Wide range of rated load voltage 90 – 264 V AC / 90 – 480 V AC
– High insulation for input and output
– C-R Snubber, Zero Cross function
– Improved safety and operability by Heat sink one body type

Suffix code

Model

Code

Information

HSR

-SL

□

Slim type Single phase solid state relay

Input Control Voltage3

4 – 32 V d.c

Contact

–

1 contact

2 contact

Rated load current

15 A

25 A

40 A

Rated load voltage

90 – 264 V a.c (Low voltage)

90 – 480 V a.c (High voltage)

Operation method
(Switching Mode)

Zero Cross Switching

Random Switching

※ 2 contact : Only available 15 A items (HSR-SLD2C152Z, HSR-SLD2C154Z)

Specification

Model	LOW		HSR-SLD152Z	HSR-SLD252Z	HSR-SLD402Z
	HIGH		HSR-SLD154Z	HSR-SLD254Z	HSR-SLD404Z
W×H×D (㎜)			17.4×99×98.5		44.4×99×98.5
Input	Rated Voltage		5 – 24 V d.c
	Voltage use range		4 – 32 V d.c
	Impedance		Less than 4 kΩ
	Operation Voltage		More than 3 V d.c
	Reset Voltage		Less than 1.5 V
Load	Rated load voltage	LOW	90 – 264 V a.c
		HIGH	90 – 480 V a.c
	Peak voltage (No repetition)	LOW	600 V
		HIGH	800 V	1200 V
	Rated load current		15 A	25 A	40 A
	Frequency		50/60 Hz
	Input current (8.3 ms No repetition)	LOW	170 A	260 A	420 A
		HIGH	170 A	250 A	370 A
	Leakage current		20 ㎃ max.
	Output ON voltage dropping		1.6 V (R.M.S) max.
	Zero cross Function		Available ( R type is not available)
Response Time			1/2 Cycle + 1 ms max. (R type below 1 ms)
Insulating Resistance			500 V d.c 100 ㏁(Between the input / output and case)
Dielectric strength			3,000 V a.c (For 1 min at 60 Hz)
Vibration resistance			10 – 55 ㎐ Double amplitude : 1.5 ㎜ each X,Y and Z direction for 2 hours
Shock resistance			1,000 ㎨, X, Y, Z each axis 3 times
Storage Temperature			-30 ℃ ~ 90 ℃
Ambient Temperature			0 ℃ ~ 40 ℃ (Without condensation)
Ambient Humidity			45 ~ 85 %R.H.
Weight			Approx 230 g(Including packing box)		Approx 372 g(Including packing box)
